4.3.6 Signals polarity Configuration
When performing a CAN installation this slide is not active (see image 1 below).
Click “Next” to continue
4.3.7 Camera Calibration
NOTE: Please perform this process while seated in the drivers seat
1. Locate the TAC Target exactly in the middle of the vehicle's front bumper, as
close as possible to the bumper.
2. For Trucks and Buses with No Front Engine Hood (flat nose) locate the TAC
Target exactly 1 meter from the middle of the vehicle's front bumper (verify
exact middle position be using any flat 1 meter pole).
3. Click on “Calculate Close TAC”.
