4.3.4.1 Camera Position Measurements
Measure the following dimensions using a measuring tape or any other
appropriate measurement tool:
Camera Height from the ground:
Lateral distance from the camera to the right and left windshield edges:
Horizontal distance to the front end (i.e. end of front bumper) of the vehicle.
For example, this value should be 0.1cm for flat nosed trucks.
When done, click “Next”
