Preparing the Installation
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Non-Square Rooms
When viewing a 360° (full) image in the browser, you will notice that the top and bottom of
the image is not fully visible, i.e. some image information has been clipped. This is not a
fault of the camera, but intended behavior that aims at achieving the best possible utiliza
-
tion of the image sensor by the camera software. Bearing this in mind, it is advisable to
install the Q25 in rectangular room ceilings so that the arrow marked OBEN/ TOP points
towards one of the longer walls of the room as shown in the figure.
Original full image
from the Q25 (ceil-
ing installation in a
rectangular room)
