Mounting the Camera with the In-Ceiling Set
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Required Parts
Please check that all components supplied with the In-Ceiling Set are present in the original
packaging first. The following additional tools are required for installation:
• Power drill with matching hole saw (150 mm diameter) or jigsaw
• MOBOTIX Drilling Templates (at the end of this manual)
• Scissors to cut out the template
• Pen to mark the hole positions
• Two blue In-Ceiling wrenches from the In-Ceiling Set
• Materials and tools needed to connect the pre-installed MOBOTIX network cable in
the camera with the on-site network cable.
• Soft cotton cloth to clean the front of the lens
