Mocka Kirra - Page 7

Kirra Desk
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
x2
x2
7
12Drawers x3 11 Drawers x3
15
10
11
12
Insert 4x bolts (C) into panel [10]. Tighten with a screwdriver.
Insert 8x bolts (C) into panels [15]. Tighten with a screwdriver.
Attach panels [11] and [12] to panel [10] and secure with 4x locking
nuts (D). Tighten with a screwdriver. Attach panels [16] and [17] to
panels [15] and secure with 8x locking nuts (D). Tighten with a
screwdriver.
