Bridge mode LAN-Clients IP's in WLAN Transparency Note
LAN Client
Cloning
1 1 (LAN Client
IP)
all ports IP- and MAC-address of the LAN-Client is
registered in the WLAN.
Single Client
NAT
1 1 (MC IP) all ports IP- and WLAN-MAC-address of the MC is
registered in the WLAN.
NAT as many 1 (MC IP) Ports def.
by config
IP- and WLAN-MAC-address of the MC is
registered in the WLAN.
Level 2 Bridge as many n LAN-Clients +
1
all ports All LAN-Client-IP's and the MC-IP are
registered with the WLAN-MAC-address of
the MC.
MWLC-Mode as many 1 (MC IP) all ports Only the IP- and the WLAN-MAC-address of
the MC is registered in the WLAN.
4.1 LAN Client Cloning
In this mode the device connected to the LAN port of the MC determines the IP- and the MAC-address of the
WLAN connection that the MC establish to the WLAN infrastructure. The configuration and monitoring of the
MC is done via the IP address of the LAN-Client. If only one LAN client is connected to the MC, this mode
should be preferred.
4.1.1 Parameter for the “LAN Client Cloning mode”
In “LAN Client Cloning mode” the wireless connection is activated only when the LAN client is connected and
data packets are received via the LAN port.
Parameter Optionen Default Funktion
LAN client Type Autodetect
static
DHCP
Autodetect The MC can detect the IP address of the LAN-Client
automatically. Nevertheless the user can configure
the mode how the LAN-Client gets its IP address.
LAN-Client IP 0.0.0.0 If the LAN-Client IP is fixed and known the user can
configure that address here.
LAN Client Netmask 255.255.255.0 If the LAN - Client does not use DHCP the network
mask the LAN-Client uses has to be typed here.
LAN Client Gateway 0.0.0.0 If the LAN - Client does not use DHCP the gateway
IP the LAN-Client uses has to be typed here.
Bridge IP 0.0.0.0 With this parameter the user can define the IP that
the MC device will use for communication on the
LAN side.
Timeout 30 The MC device tests permanently the connection to
the LAN-Client. If the connection is interrupted
because for example the LAN-Client is switch of, the
MC device will switch of the WLAN interface. This is
the timeout in seconds the MC device will switch of
the WLAN interface if the connection to the LAN
Client gets lost.
Stay connected off If the MC device should hold the WLAN connected
even if the LAN-Client is down, this option can be
activated.
MC Manual Version 2.10c
