modec MC89 - Batteries and Chargers

11
Uncertainty of measure
K = 3 dB
Values established from an equivalent apparatus.
Value of vibration emission
Ah < 2,5 m/s²
Uncertainty of measure
K = 1,5m/s²
Values established from an equivalent apparatus. Electric motor voltage : 18V DC
b. Batteries and chargers
Chargers
Technical data
BAT145
BAT146
Mains voltage (input)
220-240 V AC
220-240 V AC
Mains frequency
50 / 60 Hz
50 / 60 Hz
Charging voltage (output)
10,8 – 18 V DC
10,8 – 18 V DC
Rapid charging
Max 6A
Max 8A
Permitted charging temperature range
-5°C / +55°C
-5°C / +55°C
Safety class
II
II
Weight
0,8 kg
1,1 kg
Quick charger BAT146 Standard charger BAT 145
1-1 : Charging station
1-2 : Battery pack
1-3 : Remaining charge time display (BAT146 only)
1-4 : Charge status display
1-5 : Cable holder
1-6 : Vents (BAT146 only)
Start charging :
Before use, the cable must be completely unwound from the recess (1-5).
 Insert the charger mains plug in the socket.
 Push the battery pack (1-2) into the charging station (1-1)
BAT146
