Hardware & Tool required
Hardware & Tool required
Please put Chair back (1) upside down on a carpeted or padded area.
Then open the black fabric which is attached by the Velcro from back to front on bottom of the Seat Frame (2), The inside of
the Seat Frame (2) will now be visible.
Attach Seat Frame (2) to Chair Back (1) by using 1 pieces of Blot (A), 1 pieces of Spring Washer (E) and 1 pieces of Flat
Waher (D) as shown.
DO not fully tighten Bolt (A) at this step also.
STEP 1:
Attach Seat Frame (2) to Chair Back (1) by 4 pieces of Bolt (C), 4 pieces of Spring Washer (E) and 4 pieces of
Flat washer (D) as shown.
Do not fully tighten Bolt (C) at this step.
STEP 2:
Page 2 of 3
Ax1 Dx1 Ex1
Cx4
Dx4 Ex4
1
2
F
A
E
D
Fx1
1
2
F
Fx1
C
E
D
Customer Service 609-256-9000
www.modway.com
EEI - 1384/1491/3779 CHAIR
To Next Page
