PAGE 3 OF 20
Components Carton Placement
Carton 1 of 2 Carton 2 of 2
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
x2
x1
1 x1
2 x1Bottom Board
Top Board
5 x3Adjustable Shelf
10
12
x16 Fixed Shelf
Support Board 1 Hutch
x311 Support Board 2 Hutch
Front Board Hutch
x113 Back Board Hutch
x118 Bottom Skirt 2
x1
x1
20 x1Front Drawer
19 x1Bottom Skirt 3
21 x1Side Drawer Left
23
x122 Side Drawer Right
Back Drawer
x124 Bottom Drawer
Hardware Pack
x1Hardware Pack
3 x1Side Board Left
x14 Side Board Right
x17 Bottom Skirt 1
x28 Frame Door
x29 Support Board 1
x114 PVC Board
x215 Support Board 2
x116 Center Board Left
x117 Center Board Right
x125 Door Left
x128 Support Board 4
x129 Support Board 5
x130 Support Board 6
x231 Support Board 7
x232 Back Board
26 x1Door Right
27 x1Support Board 3
Provided hardware:
What you need:
Phillips Head Screwdriver
Phillips
A
x42Cam Bolt Ø6 x 35 mm
B
x38Cam Lock Ø15 mm
C
x49Wood Dowel Ø8 x 30 mm
D
x16Screw M 6.4 x 25 mm
E
x7Screw M 8 x 39 mm
F
x12Shelf Pin
G
x2Screw Cap Ø15 mm
H
x2Stopper
I
x3Handle
J
x7Screw M 4 x 20 mm
K
x2Handle
L
x48Screw M 4.5 x 12.5 mm
M
x16Wedge
N
x16Screw M 3.5 x 15.5 mm
O
x4Screw Cap Ø15 mm
P
x2Allen Key
Q
x1Joining Strip
R
x4Cam Lock Ø12 mm
S
x2Wood Dowel M6 x 30mm
T
x4Screw M 7 x 50 mm
U
x4Screw M 6 x 10.5 mm
V
x6Screw M 3.5 x 13 mm
W
x2Silicon Bumper
X
x6Floor Glide
Y
x18Wood Dowel M5 x 20mm
RM30A
x1Drawer Runner
HS26C
x8Hinge
Z
x2Rubber
