5.6 Restarting the Automatic Air Purge Timer (After Start-Up)
After the original start-up of the system (Section 5.5), you can Run, Hold, or End the automatic air
purge timer.
Operation
Action
Indication
To Run the Timer
Press and quickly release
+
Beacon – RUN = On
OP4 = On
Scrolling test display: “AUTO AIR PURGE”
To Hold the Timer
Press and quickly release
+
Beacon – RUN = Flashing
OP4 = On
Scrolling test display: “TIMER HOLD”
To End the Timer
Press and hold +
for more than 1 second
Beacon – RUN = Off
OP4 = Off
Timer has timed out
(END state)
Beacon – RUN = Off
OP4 = Off
5.7 Manual Air Purge Operation (After Start-Up)
There is a manual purge button that can be used after the Automatic Air Purge time has expired.
This is a momentary push button.
5.8 Remote Set Point and Retransmission “Scaling”
Scaling of the 4-20mA and 0-10V signals for this option are as follows:
 4mA or 0V = minimum system operating temperature.
 20mA or 5V, 10V = maximum system operating temperature.
Note: Maximum system operating temperature value is reflective of the series system purchased,
(refer to serial tag for maximum operating temperature located on Mokon system).
Consult customer service at Mokon factory (716) 876-9951, regarding
system’s minimum and maximum temperatures if there are any
questions.
