9.1 Duratherm Model Codes
Duratherm Model Codes
Model #
DT2009AA
D Duratherm
00 No heat
T
3/4 HP - 25 GPM
09 9 kW
R
1-1/2 HP - 40 GPM
18 18 kW
N
3 HP - 60 GPM
24 24 kW
O
5 HP - 80 GPM
36 36 kW
P
7.5 HP - 100 GPM
48 48 kW
Q
10 HP - 120 GPM
72 72 kW
Z
Dual Zone - 3/4 HP 25 GPM
96 96 kW
Y
Dual Zone - 1-1/2 HP 40 GPM
W
Dual Zone - 3 HP 60 GPM
U
Dual Zone - 5 HP 80 GPM
C
Special, Open Circuit
V
Dual Zone - 7.5 HP 100 GPM
D
Special, Closed Circuit
X
Dual Zone - 10 HP 120 GPM
H
Obsolete
B
HTP - 1-1/2 HP 25 GPM 300
o
F Max
J
Obsolete
C
HTP - 2 HP 40 GPM 300
o
F Max
3
Eurotherm 1/4 or 1/8 DIN, Open Circuit
F
HTP - 3 HP 60 GPM 300
o
F Max
4
Eurotherm 1/4 or 1/8 DIN, Closed Circuit
E
HTP - 5 HP 80 GPM 300
o
F Max
5
*Eurotherm 1/16 DIN, Closed Circuit
D
HTP - 7.5 HP 100 GPM 300
o
F Max
8
Obsolete
A
HTP - 10 HP 120 GPM 300
o
F Max
9
Obsolete
G
Dual Zone HTP - 1-1/2 HP 25 GPM 300
o
F Max
0
*Eurotherm 1/16 DIN, Open Circuit
J
Dual Zone HTP - 2 HP 40 GPM 300
o
F Max
L
Dual Zone HTP - 3 HP 60 GPM 300
o
F Max
M
Dual Zone HTP - 5 HP 80 GPM 300
o
F Max
K
Dual Zone HTP - 7.5 HP 100 GPM 300
o
F Max
Open Circuit=no heat exchanger
H
Dual Zone HTP - 10 HP 120 GPM300
o
F Max
Closed Circuit=heat exchanger
2
230 Volts / 3 Phase / 60 Hertz
3
380 Volts / 3 Phase / 50 Hertz
4
460 Volts / 3 Phase / 60 Hertz
5
575 Volts / 3 Phase / 60 Hertz
6
415 Volts / 3 Phase / 50 Hertz
7
208 Volts / 3 Phase / 60 Hertz
8
Not used
9
Special Voltage, see option code
10
400 Volts / 3 Phase / 50 Hertz
11
380 Volts / 3 Phase /60 Hertz
12
200 Volts / 3 Phase / 50 Hertz
13
200 Volts / 3 Phase / 60 Hertz
14
230 Volts / 1 Phase / 60 Hertz
Controller
Kilowatt Capacity
See Option Code
Pump Style
Zone / HP / Pump Capacity
Voltage
