Note:
Torque of rear wheel axle self-lock nut: 600~ 900 kg-cm.
Torque of brake calliper tightening bolt: 210 ~250 kg-cm.
Torque of speed meter cable nut: 60kg-cm
5.3 Rear Wheel
Place the scooter on the main stand for maintenance.
Disassembly:
1. Exhaust pipe.
2. Lock screw nut and washer.
3. Rear wheel.
Note:
1. Use vacuum to clean wheel rim and lining.
2. The transverse eccentricity should be within 3.0mm.
3. The lateral eccentricity should be within 3.0 mm
