1. The battery liquid is highly corrosive. Avoid contact of the liquid with skin or eye.
If any contact occurs, wash with large quantities of clean water and in the case of
eye contact, consult a doctor.
2. The hydrogen released from battery during charging is explosive. Keep the area
well ventilated during battery charging and avoid naked flame.
Warning: Brake Fluid
Brake fluid can damage the paint and some plastics. Cover the parts that can be damaged
with cloth during maintenance of hydraulic brakes. If the brake fluid is spilt on plastic or
a painted component, remove the fluid and wash the surface with water immediately.
Warning: High Temperature of Engine
The engine cover, cylinder, and exhaust pipe can be at a high temperature after the engine
has been running. Wait for the engine to cool before working on it or use protective
gloves.
2.5 Torque Settings
(Monaco representative figure)
Standard Torque Values of Bolts and Nuts
Specification
Torque (kg-cm) Specification Torque (kg-cm)
5 mm Bolt and Nut 40 8 mm Bolt and Nut 220
5 mm Flange Bolt and Nut 50 8 mm Flange Bolt and Nut 270
6 mm Bolt and Nut 100 10 mm Bolt and Nut 350
6 mm Flange Bolt and Nut 120 10 mm Flange Bolt and Nut 400
6 mm SH Bolt and Nut 90 12 mm Bolt and Nut 550
Torque Values of Chassis Components
No.
Tightening Location Specification Torque (kg-cm)
