1 Front Wheel Axle Self-lock Nut M12 500~600
2 Brake Disk Hex Bolt M5 180~280
3 Brake Clipper Tightening Bolt M8x35 210~250
4 Speed Meter Cable Nut X 60
5 Front Fork Bearing Tightening Nut M25x1.0 600~650
6 Rear Wheel Axle Self-lock Nut M16x10 600~900
7 Rear Brake Connecting Rod Bolt M16x32 50~80
8 Rear Brake Pin Self-lock Nut M8 250~270
9 Rear Upper Cushion Tightening Bolt M10×46 200~300
10 Rear Lower Cushion Tightening Bolt M8×35 200~300
Torque Values of Engine Components
Tightening Location Specification Torque (kg-cm) Quantities
Cylinder Head Bolt M6 80~100 4
Cylinder Stud Bolt M8x182.5 500~800 2
M8x195.5 2
Cylinder Intake Pipe Stud Bolt M6x50 500~800 2
Muffler and Exhaust Pipe Tightening Screw M6 100~120 2
Muffler & Right Crankcase Upper Tightening
Screw
M8x42 300~400 1
Muffler & Right Crankcase Lower Tightening
Screw
M8x38 300~400 1
Spark Plug M10 100~120 1
Valve Gap Adjust Lock Bolt M5 50~90 2
Fuel Filter Nut Cap M30 150~200 1
Cooler Fan Lock CR M6x18 500~800 4
Wire Assembly Lock Screw M6x20 800~1000 2
Start Clutch Gear Tightening Nut M22 (R.T.) 800~1000 1
Driven Belt Pulley Assembly M12 400~600 1
Gearbox Cover Tightening Bolt M6x28 100~1200 3
M6x35 3
Gearbox Oil Fill Cover Screw M8 90~150 1
Gearbox Oil Drain Cover Screw M8x12 90~150 1
Clutch Side Cover Screw M6x40 50~80 6
M6x65 2
Starter Arm Tightening Screw M6x22 100~120 1
