1 9065 DRAIN VALVE WITH CAP
2 9056 STRAINER
3 9078 RETURN-WATER MANIFOLD GASKET
4 9056 NEOPRENE STICKING SEALING
FLANGE
5 9093 RETURN/SUPPLY MANIFOLD, MZC
6 9042 O RING FOR DERATE ORIFICE
HEAT EXCHANGER
7 9006 CIRCULATING PUMP 15/42F 115V
8 9096 NEEDLE VALVE O-RING
9 9095 BYPASS NEEDLE VALVE
10 9094 BYPASS PLUG
11 9010 AUTOMATIC AIR VENT
12 9015 FLOW SWITCH
13 For Reference Only SPRING FOR SYSTEM COVER
14 Part of LP Kit 9085 UNION REDUCER D 3.5 (GP)
14 9130 UNION REDUCER 5.4 (GN)
15 For Reference Only SAFETY VALVE DISCHARGE PIPE
16 9098 RETURN TO HX PIPE
16 9090 WELDED INLET TO SUMP
17 For Reference Only EXTENSIBLE SEALING EXT. 40
INTERNAL 25
18 9019 FAN (OR #W00. 17073)
19 9099 RETURN TO HX PIPE GASKET
20 For Reference Only SLEEVE BURNER/VALVE 2 PARTS
TO CLIP
21 For Reference Only NITRILE O-RING D 38 3.70 SHORE
22 For Reference Only COLORLESS PLASTIC CAP
23 9097 FLOW SWITCH GASKET
24 9534 WALL BRACKET
25 9210 CABINET MZ25C
26 9020 IGNITION TRANSFORMER
27 For Reference Only BACK STOP PLATE FOR MZ
(3355X80 4X1.5)
28 For Reference Only FIXING SYSTEM FOR FLUE PIPE
29 For Reference Only EXTENSIBLE SEALING;
EXT40-INTERN, 14
30 For Reference Only REDUCED FLUE OUTLET PIPE,
F75/M80 L360
31 9021 AIR PRESSURE SWITCH
APPENDIX B
DESCRIPTION
ITEM
#
PART
NUMBER
32 9533 ELBOW D.80 45º
33 9003 FLAME PROBE
34 9022 BURNER HEAD
35 9004 IGNITOR
36 For Reference Only AIR REDUCER D.29 (GN)
36 Part of LP Kit 9085 AIR REDUCTION RING D.31 (GP)
37 For Reference Only REMOVABLE PROTECTION FOR
BURNER (580 X 30 X 1.5)
38 For Reference Only GLASS BRAID RING D 12 LG 685
39 9023 SYSTEM LIMIT
40 9532 90º ELBOW D 80 WITH SENSOR
41 9024 FLUE LIMIT 76º C
42 9060 SIGHT GLASS RETAINER
43 9059 SIGHT GLASS GASKET
44 9058 SIGHT GLASS
45 9014 SYSTEM HEAT EXCHANGER
47 9069 PRESSURE RELIEF VALVE
48 2365 FLEXIBLE PIPE/SIPHON OUTLET
D.32 LENGTH 1300
49 9017 CONTROL PANEL INCLUDING WIRING
50 9066 NUT
51 For Reference Only FLANGE COCK & EXPANSION
VESSEL FOR THR
52 For Reference Only STAINLESS STEEL FLEXIBLE PIPE
MALE, 1/4 WITH ELBOW
53 For Reference Only SIGHT GLASS D 33X3
54 9080 GAS MANIFOLD CONNECTION NUT 25S
55 For Reference Only SEALING
56 9012 EXPANSION VESSEL (8 LITERS)
57 For Reference Only GAS SUPPLY
58 9005 GAS VALVE
59 For Reference Only NITRILE O-RING D.23 52X1, 78
60 For Reference Only BURNER GAS PIPE
61 For Reference Only WHITE DOOR FOR MZC 525 NOT
EQUIPPED
52 For Reference Only WHITE ABS DOOR HANDLE 90, 22,
90,79, O B
63 9206 DOOR MZ25C
64 9207 WHITE COVER MZC: WHITE DOOR
65 For Reference Only NITRILE O-RING D.8X2 80 SHORE
DESCRIPTION
ITEM
#
PART
NUMBER
