33
www.monitorproducts.com
APPENDIX B
1 For Reference Only SPRING FOR SYSTEM COVER
2 For Reference Only EXTENSIBLE SEALING;
EXT40-INTERN 14
2 BOTTOM PANEL, MZ25S 40
3 9065 FILL/DRAIN VALVE WITH CAP
4 9056 STRAINER
5 9068 WASHER
6 For Reference Only HEATING FLOW/RETURN UNIT
7 For Reference Only NEOPRENE STICKING SEALING/
FLANGE
8 9096 NEEDLE VALVE O-RING
9 9095 BYPASS NEEDLE VALVE
10 9094 BYPASS PLUG
11 9010 AUTOMATIC AIR VENT
12 For Reference Only SEAL, AFM34 D
13 9069 SAFETY VALVE MF 1/2"
14 9006 CIRCULATING PUMP 15/42F 115V
15 9099 RETURN TO HX PIPE GASKET
16 9082 DHW LEAVING-WATER ELBOW 25S
17 9081 DWH FLOW-SET ELBOW 255
18 For Reference Only MESSING MF REDUCTION
19 9080 GAS MANIFOLD RETAINER NUT
20 9013 FLASH DOMESTIC HOT WATER
CYLINDER
21 For Reference Only BRASS NIPPLE MALE 1/2 -
MALE 3/4 LONG
22 9535 WALL BRACKET
23 9212 CABINET MZ 25S
24 9008 DOMESTIC HOT WATER
THERMOSTAT
25 9020 IGNITION TRANSFORMER
26 For Reference Only BACK STOP LATE FOR MZ
27 For Reference Only FIXING SYSTEM FOR FLUE PIPE
28 9533 ELBOW D.80 45º
29 9097 FLOW SWITCH GASKET
31 9021 AIR PRESSURE SWITCH
32 9003 FLAME PROBE
33 9004 IGNITOR
34 9022 BURNER HEAD
35 9092 RETURN/SUPPLY HEAT EXCHANGE
O-RING
36 For Reference Only AIR REDUCER D29
36 9129 AIR REDUCTION RING D.31
37 Part of LP Kit 9084 SLEEVE BURNER/VALVE 2 PARTS
TO CLIP
38 For Reference Only NITRILE O-RING
39 9019 FAN (OR #W00. 17073)
40 For Reference Only EXTENSIBLE SEALING EXT. .40
INTERN 25
41 For Reference Only GALVANIZED CAST IRON BEND
42 9009 3 WAY SELECTOR VALVE SHELL
43 For Reference Only HEATING FLOW MZS
44 9015 FLOW SWITCH
45 For Reference Only WELDED INLET TO PUMP
46 9094 BYPASS PLUG
48 9018 SELECTOR VALVE MOTOR
49 2365 FLEXIBLE PIPE/SIPHON OUTLET
D32 LENGTH 1300
50 9057 CONDENSATE TRAP
51 For Reference Only GLASS BRAID RING D12 LG 685
52 9023 SYSTEM LIMIT
53 9014 HEAT EXCHANGER MZ25C / MZ25S
54 9024 ELMWOOD SAFETY THERMOSTAT
85º W/ MANUAL RESET
55 9532 90º ELBOW D80 WITH SENSOR
56 9060 SIGHT GLASS RETAINER
57 9059 SIGHT GLASS GASKET
58 9058 SIGHT GLASS
59 9017 CONTROL BOX
60 For Reference Only UNION REDUCER D 3.5
60 For Reference Only UNION REDUCER 5.4
61 For Reference Only NIRILE O-RING D 8X2 80 SHORE
62 For Reference Only BURNER GAS PIPE
63 For Reference Only NIRILE O-RING D 23.52 X 1.78
64 9005 GAS VALVE
65 For Reference Only GAS SUPPLY
66 9012 EXPANSION VESSEL (8 LITERS)
67 For Reference Only STAINLESS STEEL FLEXIBLE PIPE
MAL 1/4 WITH ELBOW
68 For Reference Only SIGHT GLASS D 33X3
69 9066 NUT
70 For Reference Only FLANGE COCK & EXPANSION
VESSEL FOR THR
71 For Reference Only COVER MZS: WHITE
72 For Reference Only WHITE DOOR MZS/THRS NOT
EQUIPPED
73 For Reference Only WHITE ABS DOOR HANDLE 50, 22,
90, 79, 0B
74 9200 DOOR MZ40
DESCRIPTION
ITEM
#
PART
NUMBER
DESCRIPTION
ITEM
#
PART
NUMBER
