APPENDIX B
DESCRIPTION
ITEM
#
PART
NUMBER
DESCRIPTION
ITEM
#
PART
NUMBER
1 9091 FILTER FILL AND DRAIN A55Y
2 9065 DRAIN VALVE WITH CAP M1/2-,3/4"
3 For Reference Only MESSING REDUCER CB 1 1/2 -
FEMALE 1/2
4 9066 NUT
5 9056 STRAINER
6 9078 RETURN WATER MANIFOLD
GASKET
7 For Reference Only NEOPRENE STICKING SEALING/
FLANGE
8 9096 NEEDLE VALVE O-RING
9 9095 BYPASS NEEDLE VALVE
10 9094 BYPASS PLUG
11 9010 AUTOMATIC AIR VENT
12 9015 FLOW SWITCH
13 For Reference Only INLET/OUTLET HEATING UNIT
14 9092 RETURN/SUPPLY HEAT
EXCHANGE O-RING
15 9006 CIRCULATING PUMP 15/42F 115V
16 For Reference Only SPRING FOR SYSTEM COVER
17 9090 SAFETY VALVE DISCHARGE PIPE
18 9098 RETURN TO HX PIPE
19 For Reference Only WHITE DOOR MSZ/THRS NOT
EQUIPPED
20 9099 RETURN TO HX PIPE GASKET
21 9019 FAN (OR #W00 17073)
22 For Reference Only COLORLESS PLASTIC CAP
23 For Reference Only WHITE ABS DOOR HANDLE 90, 72,
90, 79, OB
24 For Reference Only EXTENSIBLE SEALING EXT. 40
INTERN 25
25 9535 WALL BRACKET
26 9205 CABINET, MZ40
27 9020 IGNITION TRANSFORMER
28 For Reference Only BACK STOP PLATE FOR MZ
29 For Reference Only FIXING SYSTEM FOR FLUE PIPE
30 9200 DOOR MZ40
31 For Reference Only REDUCED FLUE OUTLET PIPE
32 9073 AIR PRESSURE SWITCH 40C
33 For Reference Only ELBOW D. 80 45º
34 9003 FLAME PROBE
35 9004 IGNITOR
36 9023 SYSTEM LIMIT
37 For Reference Only NITRILE O-RING D.38X3.70 SHORE
38 For Reference Only NITRILE O-RING D 8X2 80 SHORE
39 For Reference Only UNION REDUCER D12 D 4.20 (GP)
40 9074 BURNER FOR MZ40C
41 For Reference Only SLEEVE BURNER/VALVE 2 PARTS
TO CLIP
42 9093 RETURNS/SUPPLY MANIFOLD, MZC
43 For Reference Only TINNED GAS PIPE NOZ
44 For Reference Only MESSING M/F REDUCTION
45 For Reference Only 90 ELBOW D. 80 WITH SENSOR
46 For Reference Only GLASS BRAID RIND D. 12 LG 1070
47 For Reference Only ELMWOOD SAFETY THERMOSTAT
85º W/ MR
48 9005 GAS VALVE
49 For Reference Only NITRILE O-RING D. 23, 52X 1.78
50 For Reference Only HONEYWELL VALVE FLANGE
51 9097 FLOW SWITCH GASKET
52 For Reference Only SIGHT GLASS D. 33X3
53 9060 SIGHT GLASS RETAINER
54 9059 SIGHT GLASS GASKET
55 9058 SIGHT GLASS
56 9087 MZ40C HEAT EXCHANGE
57 9080 DWH CONNECTION NUT 255
58 For Reference Only GAS RAMP M40
59 9057 CONDENSATE TRAP
60 9104 CONTROL PANEL INCLUDED
WIRING
61 9011 SAFETY VALVE MF 1/2"
62 For Reference Only FLEXIBLE PIPE/SIPHON OUTLET
D. 32 LENGTH 1300
63 For Reference Only COVER MZC 30/40 WHITE
* For Reference Only WIRE CARRIER
* 9002 O-RING (FLUE OUTLET)
* For Reference Only EPOM STICKING SEAL PIPE 6/9
LENGTH 18
* For Reference Only EXTENSIBLE SEALING, EXT. 40-
INTERN 14
* 9101 GASKET FOR 70 MM HORIZONTAL
FLUE PIPE
* For Reference Only FLUE TEMPERATURE ALU
MEASURE SENSOR
* For Reference Only FIXING BRACKET FOR BURNER
MZ/THR
* For Reference Only VERSILIC PIPE 6X10 LENGTH 800 MM
* For Reference Only GAS BEND
* For Reference Only HEATING FLOW BEND
* For Reference Only HEATING RETURN BEND
* 9087 LP CONVERSION KIT MZ40
* 9077 COMBINATION RESET SWITCH
ASSEMBLY
* For Reference Only FIXING BRACKET FOR
IONIZATION PROBE
* For Reference Only IGNITION ANGLE WITH SCREW
* *NOT SHOWN ON DRAWING
