FG038 MK2 Divider RevA19 13-02-19 27
11.0 MAINTENANCE
WEEKLY MAINTENANCE
1 ISOLATE MACHINE FROM MAINS SUPPLY.
2 Apply grease to main piston sheave
grease nipple (42).
Note: Nipple located in cluster of six on side or end of divider. Use correct
grease gun (43) normally one pump will suffice. DO NOT use large grease gun from
oven as this could cause pipes to burst.
3 Re-connect electrical supply.
MONTHLY MAINTENANCE
1 Remove two screws (44).
2 Remove backslide oil retaining shield (45), clean and refit.
3 Refit screws.
4 Apply grease to six grease nipples, using correct grease gun (43), Lithium
L2 high temperature grease.
42
