Mooer GE150 - Connectivity Ports; Input; Left;Mono Output; Right Output

LEF T/MONO
RIG HT
9V 3 00mA
01 02 03 04 05 06 07 08
RIGHT：1/4'monojack.ConnecttotheLoutputwhenusingamonosetup.ConnecttobothLandRoutputs
fortruestereooutput.
PHONE：1/8'stereojack.Connectyourheadphonestothisoutputforpracticeorformonitoringwhenusing
theGE150asasoundcard
05
01
04
02
03
05
06
07
08
AUXIN：1/8'stereojacktoconnectanexternalaudiosourcesuchasanmp3playerormobilephone.
INPUT：1/4'monotoconnectyourinstrument.
LEFT/MONO：1/4'monojack.
USB：TypeBUSBport.ConnectaUSBcabletoaPCcomputerfordirectrecording,softwareupdatesorpreset
editingusingthededicatededitorsoftware.
OTG：MICROUSBporttoconnectcompatiblesmartphoneortabletfordirectrecording.
DCIN：9Vpowersupply.
