SHIFT
While pressing "SHIFT" is active, the screen called by the F1 to F5 switches becomes
the setting screen. If you push this switch again or select one of F1 to F5 setting screen,
"SHIFT" becomes inactive. *Refer to 1-2-6. for protection of setting screen transition
Cursor △▽
Used to scroll the items on the LCD in the direction indicated by the triangular shape
Highlights are used to indicate the action function or its value to the operator. You can change
the value of the highlighted parameter by turning the rotary knob or inputting from the numeric
keypad. *The numeric keypad is displayed on the screen after touching the same parameter
again or turning the rotary knob after specifying the parameter. For details, refer to section 2-
3-2.
STATE MONITORING AREA
In the status monitoring area shown in Figure 1-33, it is used to indicate the status of the following functions.
Start
Lights when the cycle Start signal is received.
Die Gap
Lights when the Die Gap signal is received and “DIE GAP” on the LCD is lit
Continuous
Lit when the “Continuous Extrusion” machine type is selected
Accumulator*
Lit when “Accumulator” machine type is selected
Divergent
Lit when “Divergent” die gap tooling is selected
Convergent
Lit when “Convergent” die gap tooling is selected
End of Filling
Lights at the end of the accumulator filling stroke
Point Out
Lights when each Marker point is reached
End of Extrusion*
Lights at the end of the accumulator extrusion stroke (Cushion)
SWITCH OF F1 TO F5
It is used to select the function screen displayed in the editing area shown in Figure 1-33. The contents of
the function are as follows.
F1 Profile
Controls the parison wall profile and other related functions. (When start up the control-
ler, move to this screen first)
F2 Marker
Set the program point markers. And set the slope(Speed) that do to Die gap and start
position. Internal clock time setting. PURGE/TOOLING core opening setting
F3 File
Controls the container wall thickness storage functions
F4 Monitor
Indicate the digital I/O, current value of servovalve input current and core position. Man-
ual operation is also done on this screen.
F5 Data
Displays the profile point and related function data
SHIFT→F1
SET UP Mode - Provides die gap tooling and other machine related set up functions
SHIFT→F2
Signal assign to Monitor Analog output
SHIFT→F3
Delete and Backup/Restore the storage data.(Backup/Restore for data in USB
memory)
SHIFT→F4
Machine setting setup
SHIFT→F5
Communication parameter setting of Ethernet.
