SECTION II
LIMITATIONS
MOONEY
MODEL
M20J
POWER PUNT INSTRUMENT MARKINGS
INSTRUMENT YELLOW ARC- GREEN ARC-
REDLINE
(CAUTION
NORMAL MAXIMUM
RANGE)
OPERATING
LIMIT
Tachometer 1500-1 950 1950-2700 2700 RPM
Cylinder Head
Temperature
Oil
7.5' Min.
150-245'~ 245 O F
Temperature
Grnd.Run-up
(65-1 1 8'~) (1 1 8'~)
***
NO REDLINE
Oil (IDLE ONLY) 60-90 PSI 100 PSI
Pressure 25
- 60
* **
Fuel Pressure Radial Red Line 14-30 PSI 30 PSI
Min.
14 PSI
...................................
...................................
* Yellow arc (starting and warm-up range) . . . . . . 90-100 PSI
** Radial red line (minimum idling) . . . . . . . . 25 PSI
*** Needle moves off White Dot.
-----------
I NOTE I
--
Refer to AVCO Lycoming Engine Maintenance and Operators
Manual Section on Engine Specifications and Operating
Limits for recommended cruise power and temperature
limitations.
AIRPLANE FLIGHT MANUAL
2-6
FAA APPROVED REV.
€3 6-1 2-87
ISSUED 6-2-86
