8
2. OVERVIEW OF THE UNIT
2.1. Accessories Supplied with the Unit
After unpacking, please check if you have all the following components.
NO.
Components
Quantity
NO.
Components
Quantity
User Manual 1
Drain Pipe 1
Rubber Blanket 4 Water Pipe Joint 2
Drain Connector 1
2.2. Dimensions of the Unit
Model
A
C
D
E
F
G
MR550
1000
660
681
373
380
98
MR650
1150 455 760 681 430 470 85
MR750
1150 455 760 681 430 470 85
