Morgana DigiFold Pro - Page 18

Page18
FOLDING
Thegapsettings(Gap1,Gap2&Gap3)canthenbeadjustedbyrotatingtheRoller
GapSetKnobs(seeFIG10.1onpage10).
Whensettingrollergaps,youfirstadjustthegaptoavaluegreaterthanthatrequired
andthendecreasethevaluetotherequiredsetting.(Donotsetthegap,fromavaluelower
thanthatrequired).
(i)MeasurethethicknessofthesheetusingaDigitalVernierCalliper.
(ii)SetrollerGAP1tothevernierreading.
(iii)SetrollerGAP2androllerGAP3,(forthetypeoffoldbeingproduced),usingthe
GAPSETGUIDEtableshownbelow.
Example1:-Whenproducingafold,ifGAP1is0.2(X)thensetGAP2to0.4
(2xX)andsetGAP3to0.4(2xX).
Example2:-Whenproducingafold,ifGAP1is0.3(X)thensetGAP2to0.3(X)
andsetGAP3to0.9(3xX).
IMPORTANT.
must
PROCEDURE.
HalfK1
Gate
HalfFoldonKnife1
HalfFoldonKnife2
HalfK1
HalfK2
Letter
Concertina
Gate
ClosedGate
Engineering
FOLDTYPE GAP1GAP2GAP3
GAPSETGUIDE
X
X
X
X
X
X
X
2X
X
X
X
X
X
X
2X
2X
3X
3X
3X
3X
3X
Double X2X4X
HALF
LETTER
DOUBLE
CLOSEDGATE
ENGINEERING
GATE
CONCERTINA
FOLDTYPES
OperatingtheDigiFoldPro
