Morgana DigiFold Pro - Troubleshooting Common Issues

Page47SYSTEM
TroubleShooting
Papercreaseoutofsquare
Paperjamming
Checkthatthesheetsareallsquareandexactlythesamesizebeforeloadingthe
stackontothetable.
Checkthattheadjustablesidelayhasbeencorrectlypositionedie.Nofurtherthan
0.5mm(0.020”)fromthepaperstack.
Checkthatthebladetiltmechanismiscorrectlyset.
Checkthattheleadingedgeofthepaperisnotbeingdamagedbythepapergate.
Ifthisisoccurring,checkthatthesuctionslotandthepapergatehavebeen
correctlyset.
Checkthatthefirstcrease/foldpositionisnottooclosetotheleadingedgeof
thepaper.Aminimumdistanceof50mm(1.96”)isrecommended.
CreasePositionInaccuracy
Paperfoldoutofsquare
Checkthatthecreaseprofilehasnotbeensettoodeep.
CheckthatthecorrectBladeSetisfitted.(StandardBladeSetformaterial
thicknessof0.25mm(0.010”)andabove,NarrowBladeSetformaterialthicknessof
0.25mm(0.010”)andbelow).
Note:-thebestfoldsquarenessisachievedwhenthefoldisnotonthecenterofthe
crease,buttoonesideortheother.
Checkthatthefoldistoonesideofthecreasecenterline.
Checkthattherollergapsarenottootightandsquashingthecrease.
Checkthattherollergapsarenottoolargeandallowingthepapertoslide
(especiallysoonglossypaper).
IfjammingisoccurringinthePerforator-adjusttheHubs(seePages12&44).
DigiFoldPro
