Page17SYSTEM
RollerGapSet&TiltMechanismPage.
Togettotherollergapsettingpageclickthelowertab
Rollergapsmaybeintherangeof0.05mmto1.5mm,withincrementsof0.05mm
Therollergapscanbeadjustedtosuitthethicknessofthematerialbeingcreasedor
folded;andthetypeoffoldbeingproduced.Therollergapsmayalsorequireadjustment
ifcrackingoftheprintisnoticeable.(seeFig13.1below).
SettingtheRollerGaps(Gap1,Gap2&Gap3)
Currentgapsetting
for2ndFoldRoller
Currentgapsetting
for1stFoldRoller
Recommendedgapvalues-
basedonpaperthickness.
Currentgap
settingfor3rd
FoldRoller
CurrentsetTiltAngle
RollerGap3
RollerGap1
INFEED
FIG13.1
RollerGap2
K1
K2
DigiFoldPro
OperatingtheDigiFoldPro
