Morgana DigiFold Pro - Folds in Set by Fold Mode

Page23SYSTEM
FoldSettingsPages.
TogettotheFoldsettingpageclickthelowertaborfromthe
statusarea.
IfyouhaveselectedapredefinedstandardFoldTypefromthepapersettingspage
thecreasepositionswillbesetforyou.Thesepositionscanbefinetunedby
Foldsin‘SetByFold’mode.
±0.1mm
incrementsbypressingthearrowbuttonsforeachcrease.
K1Foldtrim-Onselection
thestatusareaisreplaced
withacalculatorfor
inputtingnewvalues.
Trimrangeis-5.0to+5.0
withincrementsof0.1mm
Foldingcanbetrimmed
forfineadjustments.
Trimrangeis-5.0to+5.0
withincrementsof
0.1mm
WithFoldingturnedoffthe
deflectpositionedcanbe
trimmed.
Trimrangeis-5.0to+5.0
withincrementsof0.1mm
Foldingon/offselector
greenison&redisoff.
Thisisalsoindicatedin
thestatusarea.
DigiFoldPro
OperatingtheDigiFoldPro
