FOLDING
SettingtheDeliveryConveyorSystem.
WARNINGS:-
1.TheMachinewillstartifthedeliveryunitisnotinitsupposition.
2.Ifthedeliveryisturnedofftherollerwillfeedtothefarendofthebeltconveyorandpark
thereuntilturnedonagain.
3.Ifthedeliveryisturnedonwhenusingthe‘SetbyFold’modeofoperation;theRoller
PositionandShingleLengthareautomaticallyset,relativetothepaperlengthandtypeof
foldselected.
4.Whenusingthe‘SetbyPosition’modeofoperation;theRollerPositionandShingle
Lengthmustbeadjustedmanuallytosuitthejob.(SeeFIG17.1below).
5.Whentheoptimumsettingsfortherollerpositionandshinglelengthareachievedthey
canbestoredwiththejob.
not
NOTE.
WhensettingthemachinetodoaDoubleFoldorEngineeringFold,withapaperlengthof
279mm(11”)orless,thestackerrollerwilltraveltothefarendoftheconveyorandstop.
Thisisduetotheshortnessofthefoldedpaperexitingfromthemachine.
FIG17.1
OperatingtheDigiFoldPro
