FOLDING
Perforating
1.Perforatingandcreasingcanbecarriedoutsimultaneously.However,ifany
adjustmentismadetotherollertiltmechanisminordertocompensateforthe
perforationlinebeing’outofsquare’,thismayeffecttheaccuracyofthecrease.If
thisoccurscreasingandperforatingmustbecarriedoutasseparateoperations.
2.Byadjustingtheoutfeeddrivetyresrelativetothedrivehubsitispossibletostear
thesheet,(i.e.Byplacingthetyreontopofthehubonesideofthepaperwillstear
fasteronthatside).
Important:Theperforatorbladesareverysharpand
caremustbetakenwhilsthandling.
Donotmixthematchingpairsofbladesoranvils.
Perforatingblades1-99-41
1-99-12
1-99-10
Anvils1-99-35
Oncethemachineisset-up,theMachinecanbeusedtoperforateorcrease.
Thecomponentsandtoolsrequiredtoinstalltheperforatorarecontainedinthedespatch
kitsuppliedwiththemachine,theyarelistedbelow.
1offSetofstandardperforation‘28tooth’blades.
1offSetofstandardhardenedanvils.
1off3mmbondhuswrench/allenkey
1off2mmbondhuswrench/allenkey
Theperforatorbladesaresplitintotwomatchinghalvesand
arefittedtothedrivewheelsasshowninthephotograph
usingthefourscrewssupplied.
Ahardenedanvilisfittedtothedrivehubasshowninthe
photographalsousingthefourscrewssupplied.Againthe
anvilsaremadefrommatchinghalves.
Forperforatingandothertypesofpaper,variousspareskitsareavailablewhichcanbe
assembledtothemachineinthesamefashion.Theyarelistedbelowalongwitharange
ofscoringwheels,
56teethPartNumber-Standardstock/
fineperforations.
28teethPartNumber-Mediumstock/
Mediumperforations.
20teethPartNumber-Heavystock/
coarseperforations.
StandardPartNumber-Forallbladetypes
Notes
Perforating‘Spares’kits
