Fold Plate Setting Figures Relate to
Nearest Scale Position and are for
Guidance Only. Final Adjustment is
Likely to be Required in Either Direction.
Roller Setting Figures Relate to the
Number of Thicknesses of Stock which
need to be Inserted into the Callipers at
each End of the Appropriate Roller.
UFO FOLDER QUICK START CHART
FOLD PLATE PAPER SIZE ROLLER SETTING
TYPE POSN A5 A4 A3 A2 TOP BACK BOTTOM
TOP
70 98 139 199
1 1 3
LETTER
BOTTOM
70 99 139 199
TOP
140 198 280 N/A
1 1 3
CONCERTINA
BOTTOM
70 99 139 N/A
TOP
105 148 209 299
1 2 2
HALF
BOTTOM
D D D D
TOP
105 148 209 299
1 2 4
DOUBLE PARALLEL
BOTTOM
53 74 105 150
TOP
53 74 105 149
1 1 5
GATE
BOTTOM
104 149 210 299
TOP
157 224 315 N/A
1 1 3
ENGINEERING
BOTTOM
52 74 105 N/A
SIZE A5 A4 A3 A2 SRA2 & ABOVE
SWITCH 1 / 2 2/3/4 4/5/6 6/7/8 8 / 9
AUTO
I I or II II II II
SWITCH
SET MODE SWITCH TO STREAM TO DISABLE SHEET SPACING
