SECTION 10: CROSSFOLD UNITS
10.1 General - UFO Crossfold Units
Crossfold units can be added to the existing UFO1 and UFO2 at any time,
to give paginations of up to 16 pages.
The units available are:
UFO 5/2 two plate crossfold
UFO 5/1 one plate crossfold
UFO 6 16 page crossfold.
Installation
The crossfold’s simply plugs into the auxiliary output socket in the rear
panel of the UFO, with no other connections. The electric delivery, when
fitted to a crossfold unit, is plugged into the auxiliary socket on the
crossfold’s rear panel.
Running
The whole system can be shut down from the control panel of any one unit
simultaneously.
10.2 Description of Configuration and Folds
The design of the standard units above offers a vast range of
configurations by changing the side lay (see 10.3) plus the ability to
convey the work underneath
the machine onto the crossfold, (e.g. figure 3
overleaf).
21
