INDEX
SECTION 1: SPECIFICATION Page 2
SECTION 2: GENERAL LAYOUT Page 3
SECTION 3: SETTING UP Page 4
3.1 - side lay 4
3.2 - side lay 4
3.3 - operator manifold 4
3.4 - operator.manifold 5
3.5 - far side manifold 5
3.6 - air knobs 5
3.7 - shuttle valve 6
3.8 - paper stop block 6
3.9 - suction opening 6
3.10 - paper gate 7
3.11 - paper gate height 7
3.12 - Removal of fold plates 7
3.13 - Replacement of fold plates 8
3.14 -Setting of fold plates 8
3.15 - Setting of roller pressures 8
3.16 - Fold settings 9
SECTION 4: CONTROLS - GENERAL LAYOUT Page 10
4.1 - batching 11
4.2 - motor speeds 11
4.3 - mode of.feed 11
4.4 - size control 11
SECTION 5: MAINS INPUT PANEL Page 12
SECTION 6: DELIVERY CONVEYOR Page 12
