Specications
C2 Contour Air Drill August 2014 2-3
C2 CONTOUR AIR DRILL
Specifications and Options
Base Size
5 Frame Models
61’ (18.59 m) 71’ (21.64 m) 80’ (24.38 m) 86’ (26.21 m) 90’ (27.43 m)
Weight - 10” Spacing
25.4 cm Spacing
31,392 lb
14,239 kg
35,441 lb
16,109kg
NA
NA
NA
NA
NA
NA
- 12” Spacing
30.5 cm Spacing
29,358 lb
13,317 kg
33,264 lb
15,120 kg
38,140 lb
17,300 kg
41,000 lb
18,600 kg
43,000 lb
19,505 kg
Working
Width
- 10” (25.4 cm)
- 12” (30.5 cm)
60’ (18.29m)
61’ (18.59m)
70’ (21.34m)
71’ (21.64m)
NA
80’ (24.38m)
NA
86’ (26.21 m)
NA
90’ (27.43 m)
Number of
Shanks
- 10” (25.4 cm)
- 12” (30.5 cm)
72
61
84
71
NA
80
NA
86
NA
90
Frame Width - Main
- Wing Inner
- Wing Outer
16’ (4.88m)
12’ (3.66m)
10’ (3.05m)
16’ (4.88m)
15’ (4.57m)
12’ (3.66m)
21’ ( 6.40m)
15’ (4.57m)
14.45 (4.4m)
21’ ( 6.40m)
15’ (4.57m)
17.75’ (5.41m)
21’ ( 6.40m)
15’ (4.57m)
18.92’ (5.77m)
Transport
Position
- Width
- Height
- Length
20’ 6” (6.25m)
15’ 2” (4.62m)
34’ 10”(10.62m)
20’ 6” (6.25m)
17’ 10” (5.44m)
34’ 10”(10.62m)
25’ (7.62m)
17’ 10” (5.44m)
34’ 10”(10.62m)
25’ (7.62m)
17’ 10” (5.44m)
34’ 10”(10.62m)
25’ (7.62m)
17’ 10” (5.44m)
34’ 10”(10.62m)
Tires - Main Frame Wheels (8) 12.5L x15 FI
Load Range F
(8) 12.5Lx15 FI
Load Range F
(8) 16.5x16.1 FI
Load Range E
(8) 16.5x16.1 FI
Load Range E
(8) 16.5x16.1 FI
Load Range E
- Wing Frame
Front Castor Wheels
Dual Castor
(8) 12.5SLx15
12 Ply Rating
Dual Castor
(8) 12.5SLx15
12 Ply Rating
Dual Castor
(8) 12.5SLx15
12 Ply Rating
Dual Castor
(8) 12.5SLx15
12 Ply Rating
Dual Castor
(8) 12.5SLx15
12 Ply Rating
- Wing Frame
Rear Wheels
(1 per wing)
(4) 12.5SLx15
12 Ply Rating
(1 per wing)
(4) 12.5SLx15
12 Ply Rating
(2 per wing)
(8) 12.5SLx15
12 Ply Rating
(2 per wing)
(8) 12.5SLx15
12 Ply Rating
(2 per wing)
(8) 12.5SLx15
12 Ply Rating
- Optional
Main Frame Wheels
(8) 16.5x16.1 FI
Load Range E
(8) 16.5x16.1 FI
Load Range E
NA NA NA
Opener - Trip Out Force Increases proportionally with Packing Force to a maximum of 600 lbs (272 kg)
- Packing Force Adjustable from 70 lbs to 170 lbs (31.7 kg - 77.1 kg)
- Packer Wheel
4.50” x 16” Semi Pneumatic Otico tire
4.80” x 16” Semi Pneumatic or Pneumatic
5.50” x 16” Semi Pneumatic Otico tire
5.50” x 16” Semi-Pneumatic
4.00” x 16” “V” Crown
Opener to Ground Clearance 12” (30.5 cm)
Frame to Ground Clearance 32” (81 cm)
Frame Depth 94” (238.8 cm) center to center
Rank to Rank Spacing 47” (119.4 cm) center to center
Number of Ranks 3 Rows
Shank to Shank Spacing 30” (76.2 cm) on 10” (25.4 cm) Spacing
36” (91.4 cm) on 12” (30.5 cm) Spacing
Weight Kit Optional
Safety Lights Standard
Hitch Clevis Standard - Catagory 4
Optional - Catagory 5
Safety Chain Standard
Specifications are estimates and subject to change.
