Morris C2 Contour - Depth Adjustment

Operation
5-12 August 2014 C2 Contour Air Drill
Depth Adjustment
To adjust seed depth:
• Lift openers to raised position (allow pressure gauge
to reach zero).
• Shut tractor off and remove key.
• Ensure tractor park brake is engaged before
proceeding.
• Place “Openers” ball valve into locked position to
prevent accidental oil ow to openers.
S44355
UNLOCKED
OPENERS
LOCKED
CRUSHING HAZARD
S44446
Before servicing hydraulics - Place
STAND CLEAR - openers move rapidly
To prevent serious injury or death:
under hydraulic pressure.
WARNING
"System" valve in service position and
relieve pressure from hydraulic system.
Shut tractor off and remove key before
servicing or adjusting depth.
Place "Openers" valve in locked position
before adjusting depth or transporting.
Valve Locations
OPERATING
VALVE
PRESSURE
ADJUSTMENT
OPENERS
BALL VALVE
