Specications
2-2 August 2014 C2 Contour Air Drill
84 ft is 25’wide 17’ 10” height 43,000lbs
C2 CONTOUR AIR DRILL
Specifications and Options
Base Size
3 Frame Models
25’ (7.62 m) 31’ (9.45 m) 41’ (12.5 m) 51’ (15.54 m)
Weight - 10” Spacing
25.4 cm Spacing
14,738 lb
6,685 kg
16,025 lb
7,269 kg
20,928 lb
9,470 kg
24,622 lb
11,168 kg
- 12” Spacing
30.5 cm Spacing
13,933 lb
6,320 kg
15,155 lb
6,874 kg
19,572 lb
8,856 kg
23,137 lb
10,495 kg
Working Width - 10” (25.4 cm)
- 12” (30.5 cm)
25’ (7.62m)
25’ (7.62m)
30’ (9.14m)
31’ (9.45m)
41.67’ (12.7m)
41’ (12.5m)
50’ (15.24m)
51’ (15.54m)
Number of
Shanks
- 10” (25.4 cm)
- 12” (30.5 cm)
30
25
36
31
50
41
60
51
Frame Width - Main
- Wing Inner
5’ (1.524m)
10’ (3.048m)
5’ (1.524m)
13’ (3.962m)
16’ (4.88m)
12’ (3.66m)
16’ (4.88m)
17.5’ (5.334m)
Transport
Position
- Width
- Height
- Length
9’ 10” (3m)
13’ 6” (4.12m)
31’ 6” (9.6m)
9’ 10” (3m)
15’ 11”(4.85m)
31’ 6” (9.6m)
20’ 6” (6.25m)
15’ 2” (4.62m)
31’ 6” (9.6m)
20’ 6” (6.25m)
15’ 2” (4.62m)
31’ 6” (9.6m)
Tires - Main Frame Wheels (4)12.5Lx15 FI
Load Range F
(4)12.5Lx15 FI
Load Range F
(8) 11Lx15 FI
Load Range F
(8) 11Lx15 FI
Load Range F
- Wing Frame
Front Castor Wheels
Single Castor
(2) 12.5SLx15
12 Ply Rating
Single Castor
(2) 12.5SLx15
12 Ply Rating
Dual Castor
(4) 11SLx15
12 Ply Rating
Dual Castor
(4) 11SLx15
12 Ply Rating
- Wing Frame
Rear Wheels
(1 per wing)
(2) 12.5SLx15
12 Ply Rating
(1 per wing)
(2) 12.5SLx15
12 Ply Rating
(1 per wing)
(2) 11SLx15
12 Ply Rating
(1 per wing)
(2) 11SLx15
12 Ply Rating
- Optional
Main Frame Wheels
NA NA NA NA
Opener - Trip Out Force Increases proportionally with Packing Force to a maximum of 600 lbs (272 kg)
- Packing Force Adjustable from 70 lbs to 170 lbs (31.7 kg - 77.1 kg)
- Packer Wheel
4.50” x 16” Semi Pneumatic Otico tire
4.80” x 16” Semi Pneumatic or Pneumatic
5.50” x 16” Semi Pneumatic Otico tire
5.50” x 16” Semi-Pneumatic
4.00” x 16” “V” Crown
Opener to Ground Clearance 12” (30.5 cm)
Frame to Ground Clearance 32” (81 cm)
Frame Depth 94” (238.8 cm) center to center
Rank to Rank Spacing 47” (119.4 cm) center to center
Number of Ranks 3 Rows
Shank to Shank Spacing 30” (76.2 cm) on 10” (25.4 cm) Spacing
36” (91.4 cm) on 12” (30.5 cm) Spacing
Weight Kit Optional
Safety Lights Standard
Hitch Clevis Standard - Catagory 4
Optional - Catagory 5
Safety Chain Standard
Specifications are estimates and subject to change.
