SECTION 1
8
Specifications
Feature Specification
Instrument Type 12-lead electrocardiograph
Input Channels Simultaneous acquisition of all 12 leads
Standard Leads Acquired I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
Waveform Display Backlit, ¼ VGA 320 x 240 LCD color display
4+4 or 6+6 lead presentation
Input Impedance
Input Dynamic Range
Electrode Offset Tolerance
Common Mode Rejection
Meets or exceeds the requirements of ANSI/AAMI EC11
Patient Leakage Current
Chassis Leakage Current
Meets or exceeds requirements of ANSI/AAMI ES1
Digital Sampling Rate 40,000 s/sec/channel used for pacemaker spike detection; 1000
s/sec/channel used for recording and analysis
Resolution 1.875 microvolt LSB
A/D Conversion 20 bits
Frequency Response 0.05 to 300 Hz
Filters High-performance baseline filter; AC interference filter 50/60 Hz; low-
pass filters 40 Hz, 150 Hz, or 300 Hz
Optional Functions Optional Mortara VERITAS resting ECG interpretation with age and
gender specific algorithm
Paper Thermal roll paper; 210 mm (8.25”) wide
Thermal Printer Computer-controlled dot array; 8 dots/mm
Thermal Printer Speeds 5, 10, 25, or 50 mm/s
Gain Settings 5, 10, or 20 mm/mV
Report Print Formats Standard or Cabrera; 12, 6, or 3+1 channel
Rhythm Print Formats 12, 6, or 3 channel with configurable lead groups
Device Classification Class I, Type CF defibrillation-proof applied parts
ECG Storage Internal storage up to 20 ECG records; external storage to USB memory
stick
Weight 5.8 lbs. (2.63 kg) including battery (without paper)
Dimensions 11.25 x 7.5 x 2.75” (28.58 x 19 x 7 cm)
Power Requirements Universal AC power supply (100-240 VAC at 50/60 Hz) 110 VA;
internally rechargeable battery
