SECTION 2
15
The following equipment is necessary to use the WAM:
• One AA alkaline battery, 1.5V
• Electrocardiograph with Mortara receiver module
• Lead wire sets
• ECG electrodes
WAM with Lead Wires
Lead Wires
Power On/Off
12-Lead ECG
Acquisition
Rhythm Print
Battery
Compartment
LED Indicators
Using the Buttons
The WAM is operated by three buttons located on the front of the device:
• Power On/Off
• Acquiring a 12-lead ECG
• Acquiring a rhythm strip
Approved Battery Models
Description Manufacturer Part Numbers
Alkaline, AA-type, 1.5V Various Various
WARNING: Use of other cells may present a risk of fire or explosion.
To order additional supplies, contact a Mortara Instrument customer service representative.
