SECTION 4
30
The following chart summarizes the configuration parameters and the available options for each field.
Summary of Configuration Menus
Configuration Parameter Definition
Software Version Displays software version on printout and in configuration menu
Language Software language availability
Battery Timeout 10, 20, or 30 minutes
Time Mode 12 hour or 24-hour clock
ID Format None, Short, Sex/Age, or Sex/DOB
AC Filter None, 50, or 60Hz
Filter 40, 150, or 300Hz
Paper Speed 25 or 50mm/sec
Rhythm Paper Speed 5, 10, 25, or 50mm/sec
Interp Yes or No
Reasons Yes or No
Append UNCONFIRMED REPORT or Reviewed by:
Number of copies 0 – 9
Auto print ECG Yes or No
Display Format 4+4 or 6+6
Plot Format Standard or Cabrera; 6, 12, or 3+1 channel
12 Rhythm leads I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
6 Rhythm Leads (1 thru 6) I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6 in any combination
3 Rhythm Leads (1 thru 3) I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6 in any combination
Avg RR: Yes or No
QTc B Yes or No
QTc F Yes or No
Pace Spike Channel Yes or No
ECG Capture Last10 or Best10
Storage Warning Yes or No
