15
Step 2. Support Stand
Please refer to Assembly instruction under MVH-2
Step 3. Binocular Tubes Sub-Observation Head
Mount the Binocular tubes on the sub-observation heads and fasten in position using the
clamp screw.
Step 4. Trinocular / Binocular Tube Main Observation Head
Mount the Trinocular / Binocular eyepiece tube on the Main observation head and fasten
it in position using clamp screw.
Step 6. Input Plug for the Arrow Illuminator
Please refer to Assembly instruction under MVH-2
Step 7. AC Adapter
Please refer to Assembly instruction under MVH-2
Rechargeable Batteries - Nickel-Metal Hydride (NiMH)
No memory effect! - NiMH's do not develop a 'memory' like NiCad rechargeable
batteries. The memory effect occurs when a rechargeable battery is recharged before it is
fully depleted. Over time, the battery will have to be re-charged much sooner than before.
