18
IV. Troubleshooting
The field of view of the sub-
observation head is cut off.
Adjust the height of the support
stand so that the main head and the
sub-observation head are horizontal
when attached.
Specimen and arrow are not
simultaneously focused.
Adjust the diopter settings refer to Diopter
adjustment.
The arrow is not visible when
pointer is used.
The pointer colour switch is in
intermediate position.
The arrow is not visible when
pointer is used.
Allow the battery to charge
overnight.
This manual may not be reproduced or transmitted in whole or in part without
Motic’s express permission.
