MOTO GUZZI GRISO User Manual

GENERAL TECHNICAL INFORMATION
2 - 4
Griso V1100
SUSPENSIONS
Front Hydraulic upside-down telescopic fork Ø 43 mm (1.69 in); spring
preload, compression and rebound damping are adjustable.
Wheel travel 120 mm (4.72 in.)
Rear single-sided with progressive linkage, monoshock with adjustable
rebound and compression damping and spring preload
Wheel travel 110 mm (4.33 in.)
BRAKES
Front Twin stainless steel floating disc - Ø 320 mm (12.60 in), callipers with
four separate opposed pistons
Rear Stainless steel disc Ø 282 mm (11.10 in)
WHEEL RIMS
Type 3 hollow spokes in aluminium alloy, chill cast
Front 3.5" x 17”
Rear 5.5" x 17”
TYRES
Type Dunlop D208 RR - Metzeler rennsport - Pirelli diablo corsa -Michelin
pilot power
Front Size: 120/70 - ZR 17” 58 W
Inflating pressure: 2.3 atm (230 kPa)
Inflating pressure with passenger: 2.3 atm (230 kPa)
Rear Size: 180/55 - ZR 17” 73 W
Inflating pressure: 2.5 atm (250 kPa)
Inflating pressure with passenger: 2.7 atm (270 kPa)
SPARK PLUGS
Internal (long life) NGK PMR8B
External NGK BPR6ES
Electrode gap 0.6 – 0.7 mm (0.024 – 0.028 in.)
ELECTRIC SYSTEM
Battery 12 V – 18 Amp/h
Main fuses 30 A
Auxiliary fuses 3 A – 15 A – 20 A
Generator (with permanent magnet) 12 V – 550 W
BULBS
Parking light 12 V – 5 W
Low beam bulb/high beam 12 V – 55 W / 60W H4
Turn indicator light 12 V – 10 W
Stop/rear parking lights LED
Instrument panel lighting LED
Number plate light 12 V – 5 W
WARNING LIGHTS
Turn indicators LED
Oil pressure LED
Neutral LED
Side stand down LED
High beam LED
Fuel reserve LED
Alarm, gear shift indicator LED
www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
