MOTO GUZZI GRISO User Manual

GENERAL TECHNICAL INFORMATION
2 - 11
Griso V1100
DESCRIPTION Q.ty
SCREW / NUT
TIGHTENING
TORQUE
(Nm)
Note
FUEL TANK
FUEL PUMP FLANGE
Tank breather fitting 2 M6 6
Pump support to tank fastener 6 M5x16 6
TANK
Union to tank fastener 4 M5x16 5
Plug ring nut to tank fastener 4 M5X15 5
Screws to plug ring nut (aesthetic) 4 M5X15 5
Tank to frame front fastening 2 M6X35 10
Battery box and tank to frame rear fastener 2 M6X25 6
BODYWORK
FRONT
Front mudguard fastener 2+2 M5 6
Electronic control unit fastener 2 M5 6
Conveyor to frame upp. front fastener 1+1 M5 Man
Conveyor to frame low. front fastener 1+1 M5
Man
Conveyors to frame rear fastener 1+1 M5
Man
Conveyors to conveyor clos.fastener 2X3
self-
tapping
Man
REAR
Cat's eye to support fastener 1 M5 4
Cat's eye support to number plate holder fastener 2 M5x12 4
Reinforcement to number plate holder and light
fastener
1
M5 4
Number plate holder to low.clos. fastener 2 self-tapp. Man
Tail guard low.clos. to frame fastener 4 M8x35 25
Fuse bracket and relay supp. fastener 4 M5 4
ACCESSORIES
Ignition switch fastener – shear bolt 2 M8x28 Shear completely
www.guzzitek.org + www.guzzitech.com - Revente Interdite - Revendita Vietata - Resaling Forbiden - Wiederverkauf Verboten

MOTO GUZZI GRISO Specifications

General

Cooling System	Air-cooled
Final Drive	Shaft drive
Seat Height	800 mm
Engine Type	90° V-twin
Fuel System	Electronic fuel injection
Front Suspension	43mm upside-down fork
Front Brakes	Dual 320mm discs, 4-piston calipers
Frame	Tubular steel
