GENERAL TECHNICAL INFORMATION
2 - 13
Griso V1100
Pos. Description Part no.
1 Tool for swingarm shaft ring nut 05912630
2 Tool to tighten steering head AP8140190
3 Drift grip 05902732
4 Ball joint seal drift 05902733
5 Transmission box oil seal drift 05902731
6 Sprocket oil seal drift 05902735
7 Sprocket nut spanner 05902734
8 Transmission box support 05902730
9 Bevel gear pair support 05902736
10 Belt tensioning tool 06948600
11 Tool for fitting Ø 41 mm seal AP8140145
12 Disassembly operations protections AP8140149
13 Drilled rod for bleeding air from damper rod AP8140150
14
Weight to be applied to tool aprilia part# AP8140145 (tool for assembling the seal Ø 41
mm) and aprilia part# AP8140189 [tool for assembling the oil seal for hole Ø 43. Accessory
to kit aprilia part# AP8140151 (complete fork tool kit)]
AP8140146
15 Shim/Damper rod separator plate AP8140148
16 Tool to hold spacer AP8140147
A Complete fork tool kit AP8140151
