ENGINE
5 - 9
Griso V1100
• Loosen and remove the three screws and move aside
the clutch slave cylinder.
• Slide out the gearbox fluid breather line.
• Working on either side, disconnect the clamp and slide
out the oil breather line.
• Loosen and remove the two screws securing the oil
vapour hose.
• Move aside the oil vapour hose.
