Undo the screw (2) and remove the cover (3).
•
Remove the engine oil filter (5).
NOTE
NEVER REUSE AN OLD FILTER.
•
Spread a thin layer of oil on the sealing ring (4) of the new engine oil filter.
•
Fit the new engine oil filter with the spring facing downwards.
•
Refit the cover (3), screw and tighten the screw (2).
Bevel gear pair oil level
IMPORTANT
TO TOP-UP OR CHANGE THE OIL IN THE CARDAN SHAFT TRANSMISSION
UNIT, CONTACT AN Official Moto Guzzi Dealer.
Gearbox oil level
IMPORTANT
THE GEARBOX OIL MUST BE CHECKED AND CHANGED BY AN Official Moto
Guzzi Dealership.
