(LED)
IMPORTANT
TO REMOVE, CHECK AND REPLACE THE FRONT LIGHT ASSEMBLY LAMPS,
CONTACT AN Authorised Moto Guzzi Dealership
Headlight adjustment (04_20, 04_21, 04_22, 04_23)
NOTE
IN COMPLIANCE WITH LOCAL LEGAL REQUIREMENTS, SPECIFIC PROCE-
DURES MUST BE FOLLOWED WHEN CHECKING LIGHT BEAM ADJUSTMENT.
04_20
For a quick check of the correct direction of the front light beam:
•
Place the vehicle 32.81 ft (10 m) away from a vertical wall and make sure the
ground is level.
•
Turn on the low beam light, sit on the vehicle and check that the light beam
projected to the wall is a little below the headlight horizontal straight line
(about 9/10 of the total height).
(HALOGEN)
142
