03_06
Check front fork (03_06)
Operating the front brake lever, press the handlebar repeatedly to send the fork fully
down. The shock absorber should compress and extend smoothly with no signs of oil
leakage on the stanchions.
Check the tightening of all the elements and the correct operation of the front and rear
suspension joints.
IMPORTANT
TO HAVE THE FRONT FORK OIL AND OIL SEALS REPLACED, CONTACT AN
Official Moto Guzzi Dealer.
03_07
Front brake lever adjustment (03_07)
You can check the clearance between the end of the brake level and the master brake
cylinder at the point shown in the figure.
The clearance must be 0.08 in (2 mm).
IMPORTANT
IF THE FRONT BRAKE LEVER MUST BE REMOVED, CHECKED AND CHANGED
BY AN Official Moto Guzzi Dealership
Rear brake pedal adjustment
IMPORTANT
FOR REMOVAL AND REPLACEMENT OF REAR BRAKE PEDAL, CONTACT AN
Official Moto Guzzi Dealer
96
