HAND-OPERATED MODELS
a - Top housing
b - Extendable speed control tiller handle
c - Serial number decal
d - Battery cables
e - Latch release handle
f - 53.3 cm (21 in.) mount bracket
g - Composite column
h - Propeller
i - Lower unit
j - Bracket door knob
k - Steering tension collar
l - Depth adjustment collar
62253
a
b
c
d
e
f
g
h
j
k
l
i
PRODUCT OVERVIEW
6 eng

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MotorGuide X5 Series and is the answer not in the manual?

MotorGuide X5 Series Specifications

General IconGeneral
TypeElectric Trolling Motor
Battery IndicatorYes
WeightVaries by model
ControlHand
Speed ControlVariable
Voltage12V, 24V
Thrust55 lbs, 70 lbs, 80 lbs, 105 lbs
