MotorGuide X5 Series User Manual

Specifications
NOTE: Freshwater models are abbreviated as FW . Saltwater models are
abbreviated as SW .
Model Control Type Volts
Speeds
Forward/
Reverse
Sonar
Peak
Thrust
Shaft
Length
X5‑55
FW
Foot pedal/
cable steer
FW 12 V Variable No
24.9 kgf
(55 lbf)
114.3 cm
(45 in.)
X5‑55
FW
Foot pedal/
cable steer
FW 12 V Variable Yes
24.9 kgf
(55 lbf)
114.3 cm
(45 in.)
X5‑70
FW
Foot pedal/
cable steer
FW 24 V Variable No
31.8 kgf
(70 lbf)
114.3 cm
(45 in.)
X5‑70
FW
Foot pedal/
cable steer
FW 24 V Variable Yes
31.8 kgf
(70 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable No
36.3 kgf
(80 lbf)
91.4 cm
(36 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable No
36.3 kgf
(80 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable Yes
36.3 kgf
(80 lbf)
114.3 cm
(45 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable No
36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable Yes
36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable No
36.3 kgf
(80 lbf)
152.4 cm
(60 in.)
X5‑80
FW
Foot pedal/
cable steer
FW 24 V Variable Yes
36.3 kgf
(80 lbf)
152.4 cm
(60 in.)
X5‑80
FW
Extendable
hand/
twist‑tiller
FW 24V Variable No
36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
SW
Extendable
hand/
twist‑tiller
SW 24V Variable No
36.3 kgf
(80 lbf)
127.0 cm
(50 in.)
X5‑80
SW
Extendable
hand/
twist‑tiller
SW 24V Variable No
36.3 kgf
(80 lbf)
152.4 cm
(60 in.)
X5‑105
FW
Foot pedal/
cable steer
FW 36 V Variable No
47.6 kgf
(105 lbf)
114.3 cm
(45 in.)
X5‑105
FW
Foot pedal/
cable steer
FW 36 V Variable Yes
47.6 kgf
(105 lbf)
114.3 cm
(45 in.)
PRODUCT OVERVIEW
eng 7

MotorGuide X5 Series Specifications

General

Type	Electric Trolling Motor
Battery Indicator	Yes
Weight	Varies by model
Control	Hand
Speed Control	Variable
Voltage	12V, 24V
Thrust	55 lbs, 70 lbs, 80 lbs, 105 lbs
