MotorGuide X5 Series - Product Overview; Cable Steer Model Components

X5‑55/X5‑70/X5‑80/X5‑105 MotorGuide Trolling Motor
CABLE STEER MODELS
a - Top housing
b - 53.3 cm (21 in.) mount bracket
c - Latch release handle
d - Foot pedal
e - Momentary on button
f - 3‑position switch
g - Speed control knob
h - Battery cables
i - 61 cm (24 in.) mount bracket (optional)
j - Propeller
k - Lower unit
l - Composite column
m - Bracket door knob
a
b
58588
c
d
e
f
g
h
i
j
k
l
m
PRODUCT OVERVIEW
