Motorline MC2 User Manual

9A 9B
PTPT
03. CONFIGURATION 03. CONFIGURATION
EXTENDED MENU 1 EXTENDED MENU 2
The control board is supplied by the manufacturer with an extended menu 2, which
provides access to more functions to the control board.
To access the extended menu 2 options proceed as follows:
01. Enter the extended menu 1 (see page 06.B).
02. Press continuously the SET button for 5 seconds and the T.PAUSA and T. RIT.
ANTE LEDs will flash simultaneously.
03. You have 30 seconds to select functions from the extended menu 2 (using the
SEL and SET button), and after this time the control board returns to the main menu.
EXTENDED MENU 2
LED LED OFF LED ON
• AUT/P.P.
Follow Me OFF Follow Me ON
• CODE
Pre Lightbulb OFF Pre Lightbulb ON
• CODE PED.
Lightbulb on pause OFF Lightbulb on pause ON
• INB. CMD. AP
Soft start OFF Soft start ON
• T. M OT.
Electronic lock PED OFF Electronic lock PED ON
• T. MOT. PED
PUL=PUL | PED=PED PUL=AB | PED=FECH
• T. PAUSA.
Intermittent simultaneously
• T. RIT. ANTE
Intermittent simultaneously
With the pause time programmed, it is possible to trigger "Follow Me" option.
With this option enabled, whenever the photocells detected the passage of a user/
object, the control board triggers the closing maneuver after 5 seconds.
Activate (LED ON) / deactivate (LED OFF) function:
01. Enter the extended menu 2.
02. Press once the SET button and the AUT/P-P LED starts flash.
03. Press once SET button to enable / disable the function.
The AUT/PP LED ON signals that the function is activated and the AUT/PP LED OFF
signals that the function is disabled.
• AUT/P-P | FOLLOW ME
With the functioning in pre lightbulb, the output 03 and 04 (CN2) will always be activa-
ted 3 seconds before the automation start a movement. When disabled, the function
returns lightbulb.
The control board is supplied by the manufacturer with the pre lightbulb disabled.
Activate (LED ON)/deactivate (LED OFF) function:
01. Enter the extended menu 2.
02. Press SEL button as often as necessary until the LED CODE starts to flash.
03. Press once SET button to enable / disable the function.
The LED CODE ON signals that the function is activated and the LED CODE OFF signals
that the function is disabled.
• CODE | PRE LIGHTBULB/LAMP.CORT
With this option enabled, whenever the motor is in pause time at output 110/230V for
lightbulb will stay on.
The control board is supplied by the manufacturer with the lightbulb during pause time,
disabled.
Activate (LED ON) / deactivate (LED OFF) function:
01. Enter the extended menu 2.
02. Press SEL button as often as necessary until the LED CODE PED starts to flash.
03. Press once SET button to enable / disable the function.
The LED CODE PED ON indicates that the function is activated and the LED OFF signals
that the function is disabled.
• CODE PED | OPERATION OF OUTPUT 110/230V FOR LIGHTBULB DURING THE PAUSE TIME
EXTENDED MENU 2
Activate (LED ON) / deactivate (LED OFF) function:
01. Activate the extended menu 1.
02. Press SEL button as often as necessary until the T. MOT. PED. LED starts to flash.
03. Press SET button for 1 second.
04. The T. MOT. PED. LED ON indicates that the function is activated and the T. MOT. PED.
LED OFF indicates that the function is disabled.
